| 型号 | 缩略图 | 输出功率 | 输入电压 | 输出电压 | 输出电流 | 输出路数 | 隔离电压 | 封装形式 | 外形尺寸mm | 规格书 | 样品申请 |
|---|---|---|---|---|---|---|---|---|---|---|---|
| D1-A0324S |
|
1W | 3.3 (3.0-3.6)VDC | ±24VDC | ±21mA | 2 | 1500VDC | SIP | 19.65*6.0*10.16 | ||
| D1-A0303S |
|
1W | 3.3 (3.0-3.6)VDC | ±3.3VDC | ±152mA | 2 | 1500VDC | SIP | 19.65*6.0*10.16 | ||
| D1-A0305S |
|
1W | 3.3 (3.0-3.6)VDC | ±5VDC | ±100mA | 2 | 1500VDC | SIP | 19.65*6.0*10.16 | ||
| D1-A0309S |
|
1W | 3.3 (3.0-3.6)VDC | ±9VDC | ±56mA | 2 | 1500VDC | SIP | 19.65*6.0*10.16 | ||
| D1-A0312S |
|
1W | 3.3 (3.0-3.6)VDC | ±12VDC | ±42mA | 2 | 1500VDC | SIP | 19.65*6.0*10.16 | ||
| D1-A0315S |
|
1W | 3.3 (3.0-3.6)VDC | ±15VDC | ±34mA | 2 | 1500VDC | SIP | 19.65*6.0*10.16 |
