| 型号 | 缩略图 | 输出功率 | 输入电压 | 输出电压 | 输出电流 | 输出路数 | 隔离电压 | 封装形式 | 外形尺寸mm | 规格书 | 样品申请 |
|---|---|---|---|---|---|---|---|---|---|---|---|
| AW02-AS03 |
|
2W | 85-305VAC/100-430VDC | 3.3VDC | 610mA | 1 | 4000VDC | DIP | 32.5*20.5*15 | ||
| AW02-AS05 |
|
2W | 85-305VAC/100-430VDC | 5VDC | 400mA | 1 | 4000VDC | DIP | 32.5*20.5*15 | ||
| AW02-AS09 |
|
2W | 85-305VAC/100-430VDC | 9VDC | 225mA | 1 | 4000VDC | DIP | 32.5*20.5*15 | ||
| AW02-AS12 |
|
2W | 85-305VAC/100-430VDC | 12VDC | 170mA | 1 | 4000VDC | DIP | 32.5*20.5*15 | ||
| AW02-AS15 |
|
2W | 85-305VAC/100-430VDC | 15VDC | 135mA | 1 | 4000VDC | DIP | 32.5*20.5*15 | ||
| AW02-AS24 |
|
2W | 85-305VAC/100-430VDC | 24VDC | 85mA | 1 | 4000VDC | DIP | 32.5*20.5*15 |
